Automatic Electric Projection Screen
Model: Wireline Advantage
- Up to 29’ of cable to accommodate appropriate viewing height in rooms with high ceilings
- Available without trim flange for non-ceiling recessed applications
- Slim-Tab, a lower profile and stronger tab design to keep your screen perfectly taut
- Tensioning Cable System to prevent warping and ensure even lateral tension
- UL Plenum rated case
Product Info
Tech Specs
Documents
Other Options
Designed for large venues, the Wireline uses thin steel cables up to 29 feet instead of black drop to lower the screen to an appropriate viewing height.
The extra step of finishing the screen with trim is also eliminated because the Advantage line of projection screens is designed with ceiling trim already in place. Once the screen is installed, the screen’s trim conceals the rough opening eliminating the need to complete additional trim work.
Sliding installation brackets make it easy to attach the screen housing to the structure above the drop ceiling.
Tensioned screens ensure the smoothest surface possible, and the Wireline™ Advantage® screen features simple in ceiling installation.
- Up to 29’ of cable to accommodate appropriate viewing height in rooms with high ceilings
- Available without trim flange for non-ceiling recessed applications
- Slim-Tab, a lower profile and stronger tab design to keep your screen perfectly taut
- Tensioning Cable System to prevent warping and ensure even lateral tension
- UL Plenum rated case
- Standard with radio frequency motor and hand-held remote
- Optional radio frequency control accessories include single channel wall switch, dry contact interface, and RS-232 interface
- Standard black backing retains projected brightness on front projection surfaces
- Aspect Ratio - 16:10
- Aspect Ratio - 16:9
- CE Certified - No
- Motorized - Yes
- Projection Screen Mount Type - Ceiling-Recessed
- Projection Screen Surface - Other
- UL Listed - Yes
- Warranty - Yes
- Spec Sheet available - Yes
- AC Voltage: 120 Volts
- Current Draw: 3 Amps
- Warranty (Length/Type): 1 Year Limited
- Certifications: UL
- Projection Type: Electric Front
- Screen Material: Vinyl
Electric Projection Screen
250 kb
- Data Sheet
Electric Projection Screen
352 kb
- Other
Electric Projection Screen
68 kb
- Other
